| A vast array of combo water/waste tank sizes ensures you the right fit for
your vessel needs.
Feature nominal wall thickness of 0.300"
Resin meets FDA spec CTF177 1520 requirements
Satisfies all U.S. Coast Guard standards
Provides standard NPT openings for vent, fill & drain.
Polyethylene tanks will not filter taste into water or emit waste odors.
Exclusively manufactured by Moeller: your leader in innovation, design.
Moeller Water/Waste Tank Selection
Chart
| Model # |
Gallons |
Length |
Width |
High |
| 041204 |
4 |
11 3/4" |
10 1/4" |
9 1/4" |
| 041206 |
6 |
16" |
11 3/4" |
8" |
| 041209 |
9 |
17" |
13 3/4" |
10 1/4" |
| 041215 |
15 |
24 1/4" |
15 1/4" |
8 3/4" |
| 041220 |
20 |
21" |
17" |
14" |
| 041224 |
24 |
22 1/4" |
22 1/2" |
12" |
| 041225 |
25 |
29 1/2" |
16 5/8" |
12 3/4" |
| 041229 |
29 |
23 1/2" |
20" |
15 1/2" |
| 041230 |
30 |
28" |
23" |
11 1/2" |
| 041239 |
39 |
32" |
21 1/2" |
14 1/2" |
| 041245 |
45 |
35 1/4" |
20 7/8" |
15 1/2" |
3 Fitting kits are also available.
1. Moeller 041311 Straight Adapter Kit, which contains all fittings needed to
adapt tank to 1/2" vent line and 1 1/2" inlet/discharge.
2. Moeller 041390 90 Degree Adapter Kit, which contains all fittings needed
to adapt tank to 1/2" vent line and 1 1/2" inlet/discharge.
3. Moeller 041336 Relocation Kit. Contains all fittings and parts needed for
a custom install where you need to move the location of the inlet-outlet
ports.
